zone are clearly visible in these seismic reflection images
taken near the Juan de Fuca Ridge (A). Nedimovic and his colleagues
identified the sub-Moho structures (visible in B) as solidified
magma lenses more than five miles beneath the surface, evidence
that the lower crust may be generated by more than one magma
source.
Some of the highest quality images ever taken of the Earth’s lower crust reveal that the upper and lower crust form in two distinctly different ways. A team led by researchers from Columbia University’s Lamont-Doherty Earth Observatory published the results of their work in the August 25 issue of the journal Nature.
The Earth’s oceanic crust is formed from magma bodies located beneath mid-ocean ridges. Although axial magma chambers, magma bodies located in the mid-crust, are known to be responsible for generating the upper oceanic crust, it has so far been unclear if the lower crust is formed from the same source or if it primarily arises from deeper “magma lenses” — smaller bodies located at or near the base of the crust.
Researchers from Lamont-Doherty as well as the Scripps Institution of Oceanography and the Woods Hole Oceanographic Institution collected seismic data of the oceanic crust beneath the seafloor off the coast of Washington, Oregon and northern California. To form the images, they analyzed sound waves that bounced off of structures deep in the Earth, a process similar to that of creating an ultrasound image. The resulting images are the first of their kind showing solidified lenses and sills, narrow lateral intrusions of magma, embedded within the crust/mantle boundary known as the Moho transition zone.
The presence of such bodies that deep near a mid-ocean ridge suggests that the lower crust is at least partially formed from several smaller sources of magma rather than from a single large source located in the middle of the crust. “This demonstrates quite strongly that the process of crustal formation is more complex than generally believed,” said Mladen Nedimovic, lead author on the study and a Doherty Associate Research Scientist at Lamont-Doherty. “It also favors the emerging view that volcanoes have a complicated plumbing system consisting of many interconnected sills and magma conduits. We obviously still have a lot to learn about what goes on beneath the surface of the Earth.”
The study was funded by grants from the Doherty Foundation and the National Science Foundation.
